Finish: Black, White, Silver or Brass
Material: Aluminium
Dimensions: Profile H: 80mm x W: 60mm
Diam: 450mm / 660mm / 900mm /1060mm / 1200mm / 1560mm / 2060mm / 2460mm / 3060mm / 4060mm / 5060mm
Drop: 2000mm or custom
Light Source: Included
Wattage: Up: 5W Down: 15W / Up: 157W / Up: 12W Down: 38W / Up :15W Down: 45W / Up: 28W Down: 80W / Up: 48W Down: 130W / Up: 60W Down: 150W / Up: 94W Down: 188W / Up: 125W Down: 251W
Lumens: Up: 450lm Down: 1350lm / Up: 1080lm Down: 3420lm / Up: 1350lm Down: 4050lm / Up: 2520lm Down: 7200lm / Up: 4320lm Down: 11700lm / Up: 5400lm Down: 13500lm / Up: 8460lm Down: 16956lm / Up: 11250lm Down: 22608lm / Up: 14130lm Down: 28260lm
Kelvin: 3000K or 4000K
Dimmable: Optional
Beam Angle: 105Deg
Warranty: 5 years
Lead Time: 12-14 weeks
Notes:
- LED Ring larger than 1200mm will be supplied in 2-8 parts (to be assembled on site). 0-10 dimming available on all Rings with driver inside the profile. Triac dimming available with external Triac dimmable driver. (wattage may vary with Triac dimmers). Dali drivers available on request. Enquire within for further variations, and custom alternatives.
- Depending on the size selected you may have 240v 1-4 power cables
Minimum radius 400mm
